Omron CP1E-ED

3-5
3 Part Names and Functions
CP1E CPU Unit Hardware User’s Manual(W479)
3-1 CPU Units
3
3-1-1 E10/14/20 or N14/20 CPU Units
 Output Arrangement
AC Power Supply and DC Power Supply
00 01 02 03
COM COM NC COM NC
CIO 100
CP1E-E10D-
COM : Common terminal
00 to 03 : Output terminal
NC : No connection
00 01 02 03
COM COM NC COM
04 05 NC
NC
COMNC
CIO 100
CP1E-14D-
COM : Common terminal
00 to 05 : Output terminal
NC : No connection
00 01 02 03
COM COM NC COM
04 05 07
06
COMNC
CIO 100
CP1E-20D-
COM : Common terminal
00 to 07 : Output terminal
NC : No connection
