540
LCD Option Board Function Section 8-6
8-6-17 LCD Contrast Setting
This function can make a setting for the LCD contrast.
Example Change the contrast of LCD display to 8.
1,2,3...
1. Switch to the Setup Mode.
2. Press the Down button to select Other.
3. Press the OK button to enter the Other menu.
4. Press the Down button to select Contrast.
5. Press the OK button to enter the Contrast Screen.
The contrast level of LCD display is 1 to 16.
6. Use the Up button to change the level to 08.
7. Press the OK button to save the setting.
8. Press the ESC or OK button to return to the previous menu.
