ix
Functions Supported by Unit Version for CP-series CPU Units
Functions Supported by
Unit Version 1.0 and 1.1
Functionality is the same as that for CS/CJ-series CPU Units with unit version
3.0. The functionality added for CS/CJ-series CPU Unit unit version 4.0 is not
supported.
CP1H CPU Units
• CX-Programmer version 6.11 or higher is required to use CP1H-X@@@@-
@/XA@@@@-@ with unit version 1.1 or 1.0.
• CX-Programmer version 6.20 or higher is required to use CP1H-Y@@@@-
@ with unit version 1.1.
Note 1. The unit version for the CP1H-X@@@@-@/XA@@@@-@ begins at 1.0.
2. The unit version for the CP1H-Y@@@@-@ begins at 1.1.
3. CX-Programmer version 7.11 or higher is required to use CP1L CPU Units
with unit version 1.0.
4. CX-Programmer version 7.3 or higher is required to use CP1L CPU Units
with 10 I/O points.
CPU Unit CP1H CPU Unit
Model CP1H-@@@@-@
CP1H-XA@@@@-@
(See note 1.)
CP1H-Y@@@@-
@
(See note 2.)
Unit version
Function
Ver. 1.1 or later Ver. 1.0 Ver. 1.1
Pulse
outputs
Allocated built-
in I/O terminals
4 axes at 100 kHz 2 axes at 100 kHz
2 axes at 30 kHz
2 axes at 100 kHz
Special pulse
output terminals
None 2 axes at 1 MHz
