Appendix A
Standard Models
CPU Units
Description Input
i
Output
i
Power
l
Model number
p
p
points
p
points supply
Relay outputs
Transistor outputs
yp
Sinking Sourcing
CPU Units with 20 I/O points 12 points 8 points
AC CPM2A-
20CDR-A
--- ---
DC CPM2A-
20CDR-D
CPM2A-
20CDT-D
CPM2A-
20CDT1-D
CPU Units with 30 I/O points 18 points 12 points
AC CPM2A-
30CDR-A
--- ---
DC CPM2A-
30CDR-D
CPM2A-
30CDT-D
CPM2A-
30CDT1-D
CPU Units with 40 I/O points 24 points 16 points
AC CPM2A-
40CDR-A
--- ---
DC CPM2A-
40CDR-D
CPM2A-
40CDT-D
CPM2A-
40CDT1-D
CPU Units with 60 I/O points 36 points 24 points
AC CPM2A-
60CDR-A
--- ---
DC CPM2A-
60CDR-D
CPM2A-
60CDT-D
CPM2A-
60CDT1-D
Expansion I/O Units
Description Input
i
Output
i
Model number
p
p
points
p
points
Relay output
Transistor output
yp
Sinking Sourcing
Expansion I/O Unit with 20 I/O points 12
points
8 points CPM1A-20EDR1 CPM1A-20EDT CPM1A-20EDT1
Expansion I/O Unit with 8 input points 8 points --- CPM1A-8ED (no outputs)
Expansion I/O Unit with 8 output points --- 8 points CPM1A-8ER CPM1A-8ET CPM1A-8ET1
