70
CPM1A-20EDR1
Terminals 00 through 07 of “1nCH” correspond to bits 00 through 07 of word
IR 1n.
250 VAC/
24 VDC
250 VAC/
24 VDC
250 VAC/
24 VDC
250 VAC/
24 VDC
Load
Load
Load
Load
Load
Load
Load
Load
CPM1A-8ER
Terminals 00 through 07 of “1nCH” correspond to bits 00 through 07 of word
IR 1n.
250 VAC/
24 VDC
250 VAC/
24 VDC
04
05
06
07
Load
Load
Load
Load
Load
Load
Load
Load
Wiring and Connections
Section 3-4
