85
CIO Area Allocations Section 4-1
FINS/TCP Connection
Status
Bit Switch Status Manipulated
by
Unit operation Reference
08 00 UDP Open Request
Switch
ON User UDP socket opened when switch is turned
ON.
Operation Man-
ual, Construc-
tion of
Applications,
SECTION 6
OFF Unit Unit turns OFF switch when open processing
has been completed (i.e., when a connection
has been made).
09 01 TCP Passive Open
Request Switch
ON User Passive TCP socket opened when switch is
turned ON.
OFF Unit Unit turns OFF switch when open processing
has been completed (i.e., when a connection
has been made).
10 02 TCP Active Open
Request Switch
ON User Active TCP socket opened when switch is
turned ON.
OFF Unit Unit turns OFF switch when open processing
has been completed (i.e., when a connection
has been made).
11 03 Send Request
Switch
ON User Send processing executed when switch is
turned ON.
(The protocol (TCP/UDP) is determined when
the socket is opened.)
OFF Unit Unit turns OFF switch when send processing
has been completed.
12 04 Receive Request
Switch
ON User Receive processing executed when switch is
turned ON.
(The protocol (TCP/UDP) is determined when
the socket is opened.)
OFF Unit Unit turns OFF switch when receive process-
ing has been completed.
13 05 Close Request
Switch
ON User Close processing executed when switch is
turned ON.
(The protocol (TCP/UDP) is determined when
the socket is opened.)
OFF Unit Unit turns OFF switch when close processing
has been completed.
14 06 (Not used.) --- --- --- ---
15 07 (Not used.) --- --- --- ---
n+23
15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00
