Command/Response Reference Section 7-3
6. The number of packets discarded because the TCP header and IP header
could not be stored in the first short buffer.
7. The number of resent packets received.
8. The number of bytes in the resend packets.
9. The number of duplicated resend packets received.
10. The number of bytes in the duplicated resend packets received.
11. The number of out-of-range data packets received. (Always 0.)
12. The number of bytes in the out-of-range data packets received. (Always 0.)
13. The number of packets where the data was larger than the window.
14. The number of bytes in the packets where the data was larger than the
window.
15. The number of packets received after closing.
16. The number of window probe packets received.
17. The number of resent ACK packets received.
18. The number of ACK packets received with no data set.
19. The number of ACK packets received.
20. The number of ACK packets received for received transmission acknowl-
edgements (ACK).
21. The number of window advertisement packets received.
UDP Status (Response) Three items of UDP information occupying 4 bytes each are returned in the
following sequence. Each value is returned as an 8-digit hexadecimal value.
1,2,3... 1. The number of packets discarded because the size of the first short buffer
was smaller than the minimum size (28) of the IP header and UDP header
when the packet was stored.
2. The number of packets discarded due to an incorrect checksum in the
UDP header.
3. The number of packets discarded because the IP overall length in the IP
header was shorter than the UDP overall length in the UDP header.
Precautions
All the above values are set to 0 if network operation stops due to incorrect
settings in the system setup.
Counting will be stopped when a count reaches the maximum value. The
maximum values are as follows:
IP, ICMP, or UDP status: 7FFFFFFF (2,147,483,647 decimal)
TC status: FFFFFFFF (4,294,967,295 decimal)
Response Codes
7-3-26 MEMORY STATUS READ
Reads the status of the Ethernet Unit’s network memory. The network mem-
ory contains 248K bytes that are used as required as for communications
buffers for communications servicing. The network memory consists of 1,472
short buffers (128 bytes each) and 64 long buffers (1,024 bytes each). Refer
to Appendix B Buffer Configuration.
Response code Description
0000 Normal
1001 Command too large
