4-4SectionDM Area Allocations
58
Number of Internode Test Timeout Errors (Ethernet Unit to CPU Unit)
Number of timeout errors (0000 to FFFF)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
m+5
The number of timeout errors that have occurred in the internode test is stored in
this word in hexadecimal.
0000 to FFFF (Hex): 0 to 65,535 times
When the count reaches FFFF (Hex), it will not go any further. The count value
will be retained until the internode test is restarted.
Number of Internode Test Response Errors (Ethernet Unit to CPU Unit)
Number of response errors (0000 to FFFF)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
m+6
The number of response errors that have occurred in the internode test is stored
in this word in hexadecimal.
0000 to FFFF (Hex): 0 to 65,535 times
When the count reaches FFFF (Hex), it will not go any further. The count value
will be retained until the internode test is restarted.
Number of Internode Test Transmission Errors (Ethernet Unit to CPU Unit)
Number of transmission errors (0000 to FFFFHex)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
m+7
The number of transmission errors that have occurred in the internode test is
stored in this word in hexadecimal.
0000 to FFFF (Hex): 0 to 65,535 times
When the count reaches FFFF (Hex), it will not go any further. The count value
will be retained until the internode test is restarted.
Number of Times Internode Test Data Did Not Match (Ethernet Unit to CPU Unit)
Number of data disagreement errors (0000 to FFFF)
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
m+8
The number of data disagreement errors that have occurred in the internode test
is stored in this word in hexadecimal.
0000 to FFFF (Hex): 0 to 65,535 times
When the count reaches FFFF (Hex), it will not go any further. The count value
will be retained until the internode test is restarted.
TCP Socket No. (1 to 8) Connection Status (Ethernet Unit to CPU Unit)
TCP connection status
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
m+9 to m+16
The connection status for each TCP socket is stored by code in this word. For
details, refer to Appendix 4 TCP Status Transitions.
