11 D6T MEMS Thermal Sensors User’s Manual (A284)
Signal Chart
(The D6T-1A-01/-02 models lack P1 through P15)
Fig. 16. Signal Terminal Flow (D6T-1A-01/-02/44L-06)
* Refer to the I2C bus specifications for the definitions of these I2C terms.
“S” : Start Condition
“Sr” : Repeat Start Condition
“P” : Stop Condition
“W/R” : Write (Lo) / Read (Hi)
“ACK” : Acknowledge reply
“NACK” : No-acknowledge reply
