6 - 65
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-9 Initial Setting Level
6
cp
c-cp
Control Period (Heating)
Control Period (Cooling)
The cooling control output and heating control
output must be assigned to relay or voltage
outputs (for driving SSR).
The control must be set to 2-PID control.
For the Control Period (Cooling) parameter, the
control must be set to heating/cooling control.
• These parameters set the output periods. Set the control periods taking the control
characteristics and the electrical life of the relay into consideration.
• For standard control, use the Control Period (Heating) parameter. The Control Period
(Cooling) parameter cannot be used.
• When the heating or cooling control output is a linear current output, the Control Period
(Heating or Cooling) parameter cannot be used.
• For heating/cooling control, the control period can be set independently for heating and
cooling. The Control Period (Heating) parameter is used for the heating control output,
and the Control Period (Cooling) parameter is used for the cooling control output.
z Related Parameters
PID ON/OFF (Initial Setting Level): Page 6-63
Function
Setting
Parameter name Setting range Unit Default
Control Period
(Heating)
0.1, 0.2, 0.5, 1 to 99 Seconds 20 for relay output
2 for voltage output (for driving SSR)
Control Period
(Cooling)
0.1, 0.2, 0.5, 1 to 99 Seconds 20 for relay output
2 for voltage output (for driving SSR)
See
See
