165
Operation Level Section 5-3
The process value is displayed on the No. 1 display, and nothing is displayed
on the No. 2 and No. 3 (E5AN/EN only) displays.
During temperature input, the decimal point position depends on the currently
selected sensor, and during analog input it depends on the Decimal Point
parameter setting.
The default setting is for a K thermocouple (5).
An s.err error will be displayed if the input type setting is incorrect. To clear
the s.err error, correct the input type or wiring, and then cycle the power.
■ Related Parameters
Input type: Page 200, Set point upper limit, Set point lower limit: Page 203 (ini-
tial setting level)
The process value is displayed on the No. 1 display, and the set point is dis-
played on the No. 2 display.
During temperature input, the decimal point position depends on the currently
selected sensor, and during analog input it depends on the Decimal Point
parameter setting.
Process Value
The Additional PV Display parameter
must be set to ON.
Monitor range Unit
Process value Temperature: According to indication range for
each sensor.
Analog: Scaling lower limit −5% FS to Scaling
upper limit +5% FS (Refer to page 303.)
EU
Function
Monitor
See
See
Process Value/Set Point (Display 1)
Process Value/Set Point (Display 2)
(E5AN/EN only)
Monitor range Unit
Process value Temperature: According to indication range for
each sensor.
Analog: Scaling lower limit −5% FS to Scaling
upper limit +5% FS (Refer to page 303.)
EU
Setting range Unit
Set point SP lower limit to SP upper limit EU
Function
Monitor
