216
Initial Setting Level Section 5-7
• The following functions can be assigned to event inputs 1 and 2.
RUN/STOP
Auto/Manual Switch
Program Start
Invert Direct/Reverse Operation
100% AT Execute/Cancel
40% AT Execute/Cancel
Setting Change Enable/Disable
Alarm Latch Cancel
• Default: Event Input Assignment 1: none
Event Input Assignment 2: stop
Note (1) PRST (Program Start) can be set even when the Program Pattern param-
eter is set to OFF, but the function will be disabled.
(2) This function can be set for heating/cooling control, but the function will
be disabled.
■ Related Parameter
SP0 to SP3 (adjustment level): Page 186
Number of multi-SP uses (initial setting level): Page 213
This parameter enables and disables square root extraction.
ev-* Event Input Assignment * (*: 1 and 2)
An event input must be assigned.
Multi-SP must not be used.
Setting Function
none None
stop RUN/STOP
manu Auto/Manual
prst Program start (See note 1.)
drs Invert Direct/Reverse Operation
at-2 100% AT Execute/Cancel
at-1 40% AT Execute/Cancel (See note 2.)
wtpt Setting Change Enable/Disable
lat Alarm Latch Cancel
Function
Setting
See
See
sqr Extraction of Square Root Enable
An analog input must be supported.
Setting range Default
on: Enabled, off: Disabled OFF
Function
Setting
