Initial Setting Level Section 5-7
The following tables show the relationships between ON/OFF combinations of
event inputs 1 and 2 and selected set points.
Number of Multi-SP Uses: 1:
Number of Multi-SP Uses: 2
• The following table shows the functions assigned when an Event Input
Assignment (1 or 2) is displayed.
Note (1) PRST (Program Start) can be set even when the Program Pattern param-
eter is set to OFF, but the function will be disabled.
(2) This function can be set for heating/cooling control, but the function will
be disabled.
• When any of the following functions is set for an Event Input Assignment
parameter, the same function cannot be set for another Event Input
Assignment parameter: STOP (RUN/STOP), MANU (Auto/Manual
Switch), PRST (Program Start), DRS (Invert Direct/Reverse Operation),
AT-2 (100% AT Execute/Cancel), AT-1 (40% AT Execute/Cancel), WTPT
(Setting Change Enable/Disable), or LAT (Alarm Latch Cancel).
Note Event inputs can be used on the E5CN-@M@ (with an E53-CN@B@N2) or
E5AN/EN-@M@-N (with an E53-AKB) Controllers. Turn event inputs ON and
OFF while the power is being supplied. Event input ON/OFF changes are
detected for inputs of 50 ms or longer.
■ Related Parameter
SP0 to SP3 (adjustment level): Page 186
Event input assignment 1 and 2: Page 216 (initial setting level), Multi-SP use:
Page 220 (advanced function setting level)
Even input 1 Selected set point
OFF Set point 0
ON Set point 1
Even input 1 Even input 2 Selected set point
OFF OFF Set point 0
ON OFF Set point 1
OFF ON Set point 2
ON ON Set point 3
Setting Function
none None
stop RUN/STOP
manu Auto/Manual Switch
prst Program start (See note 1.)
drs Invert Direct/Reverse Operation
at-2 100% AT Execute/Cancel
at-1 40% AT Execute/Cancel (See note 2.)
wtpt Setting Change Enable/Disable
lat Alarm Latch Cancel
