Initial Setting Level Section 5-7
Models with Two Event Inputs, 3 and 4
The following tables show the relationships between ON/OFF combinations of
event inputs 3 and 4 and selected set points.
Number of Multi-SP Uses: 1:
Number of Multi-SP Uses: 2
Models with Four Event Inputs, 1 to 4
Only event inputs 1 and 2 are used for the multi-SP function.
Event input assignment 3 Event input assignment 4 Description of EV3 and EV4
operation
Number of multi-
SP uses
0 Displayed (Multi-SP not used). EV3 and EV4 will perform the
operation command assigned
using the Event Input Assign-
ment 3 and 4 parameters.
1 Not displayed (Operation per-
formed with two Multi-SP
points.)
Displayed (Event input 4 not
used as multi-SP switch).
EV3 will be used for the Multi-
SP function to switch between
set points 0 and 1. EV4 will
perform the operation com-
mand assigned using the
Event Input Assignment 4
parameter.
2
Not displayed (Operation performed with four Multi-SP points.) EV3 and EV4 will be used for
the Multi-SP function to switch
between set points 0, 1, 2,
and 3.
Even input 3 Selected set point
OFF Set point 0
ON Set point 1
Even input 3 Even input 4 Selected set point
OFF OFF Set point 0
ON OFF Set point 1
OFF ON Set point 2
ON ON Set point 3
Event input
assignment 1
Event input
assignment 2
Event input
assignment 3
Event input
assignment 4
Description of EV1, EV2,
EV3, and EV4 operation
Number of Multi-
SP Uses
0 Displayed (Multi-SP not used). EV1, EV2, EV3, and EV4 will
perform the operation com-
mand assigned using the
Event Input Assignment 1, 2,
3, and 4 parameters.
1
Not displayed
(Operation
performed
with two Multi-
SP points.)
Displayed (Event inputs 2, 3, and 4 cannot be
used for multi-SP switching.)
EV1 will be used for the Multi-
SP function to switch between
set points 0 and 1. EV2, EV3,
and EV4 will perform the
operation command assigned
using the Event Input Assign-
ment 2, 3, and 4 parameters.
2
Not displayed (Operation per-
formed with four Multi-SP
points.)
Displayed (Event inputs 3 and
4 cannot be used for multi-SP
switching.)
EV1 and EV2 will be used for
the Multi-SP function to switch
between set points 0, 1, 2,
and 3. EV3 and EV4 will per-
form the operation command
assigned using the Event
Input Assignment 3 and 4
parameters.
