Initial Setting Level Section 5-7
• Multi-SP is a function for setting set points 0 to 3 in advance, and switch-
ing between these set points using a combination of event input ON/OFF
signals.
• The Number of Multi-SP Uses parameter is used to switch between using
two and four preset set points.
• Whether the Event Input Assignments 1 and 2 parameters are displayed
or hidden is determined by the Number of Multi-SP Uses parameter set-
ting.
Models with Two Event Inputs, 1 and 2
The following tables show the relationships between ON/OFF combinations of
event inputs 1 and 2 and selected set points.
Number of Multi-SP Uses: 1:
Number of Multi-SP Uses: 2
ev-m Number of Multi-SP Uses
An event input must be assigned.
Setting range Default
0 to 2 1
Function
Setting
Event input assignment 1 Event input assignment 2 Description of EV1 and EV2
operation
Number of multi-
SP uses
0 Displayed (Multi-SP not used). EV1 and EV2 will perform the
operation command assigned
using the Event Input Assign-
ment 1 and 2 parameters.
1
Not displayed (Operation per-
formed with two Multi-SP
points.)
Displayed (Event input 2 not
used as multi-SP switch).
EV1 will be used for the Multi-
SP function to switch between
set points 0 and 1. EV2 will per-
form the operation command
assigned using the Event Input
Assignment 2 parameter.
2
Not displayed (Operation performed with four Multi-SP points.) EV1 and EV2 will be used for
the Multi-SP function to switch
between set points 0, 1, 2, and
3.
Even input 1 Selected set point
OFF Set point 0
ON Set point 1
Even input 1 Even input 2 Selected set point
OFF OFF Set point 0
ON OFF Set point 1
OFF ON Set point 2
ON ON Set point 3
