Omron E5AN User Manual

41
Wiring Terminals Section 2-2
ALM1, 2, 3 can be output to auxiliary output 1, 2, 3, or changed with the
advanced function setting level.
• The relay specifications are as follows:
Event Inputs •The E5@N-@@@B supports event inputs. When event inputs 1/2 are to be
used, connect to terminals 11 to 13 or terminals 7 to 9. When event inputs
3/4 are to be used, connect to terminals 23 to 25.
• Use event inputs under the following conditions:
• The outflow current is approximately 7 mA.
Polarities during no-contact input are as follows:
E5CN/AN/EN
SPST-NO, 250 VAC, 3 A
E5GN
SPST-NO, 250 VAC, 2 A
E5CN E5CN-U
SUB2
SUB1
SUB3
SUB2
SUB1
E5AN/EN E5GN
SUB2
SUB1
SUB1
SUB2
Terminal 14 is on
the bottom.
Contact input ON: 1 kΩ max., OFF: 100 kΩ min.
No-contact input ON: Residual voltage 1.5 V max.; OFF: Leakage current
0.1 mA max.
EV1
EV2
12
11
13
EV1
EV2
11
12
13
E53-AKB in the
E5AN/EN-@M@-500-N
(for E5AN/EN)
E5GN-@@@B
E53-CN@B@N2 in the
E5CN-@M@-500
(
for E5CN
)
EV1
EV2
EV1
EV2
+
−
+
EV1
EV2
+
−
+
11
12
13
11
12
13
E53-CN@B@N2 in
the E5CN-@M@-500
(for E5CN)
E53-AKB in the
E5AN/EN-@M@-500-N
(for E5AN/EN)
E5GN-@@@B
EV1
EV2
