4 Basic Operation
4 - 34
E5@C-T Digital Temperature Controllers User’s Manual (H185)
This parameter sets the program setting method.
z Related Parameters
• The setting of the Step Time/Rate of Rise Programming parameter determines which segment
parameters are enabled.
The following table shows which segment parameters are enable according to the setting of the
Step Time/Rate of Rise Programming parameter.
*1 If the Reset Operation parameter is set to stop control, segment 0 is always a soak segment. The starting
and ending points are both the SP of segment 0.
*2 If the Segment Rate of Rise parameter is set to 0, the segment will be a step segment.
Set the unit to minutes (default) or hours in the Time Unit of Ramp Rate parameter.
z Setting Example
Setting the Step Time/Rate of Rise Programming Parameter (i.e., the
Program Setting Method)
Parameter name Display Setting range Default Level
Step Time/Rate of
Rise Programming
t-pr
time: Step time programming
pr: Rate of rise programming
time
Initial Setting Level
Parameter Setting range Unit
Setting of Step Time/Rate of Rise
Programming parameter
Step time
programming
Rate of rise programming
Segment Format Soak, ramp, or
step (default:
ramp)
---
No setting
*1
Must be set.
Soak Ramp Step
Segment SP SP lower limit to
SP upper limit
(default: 0)
EU
Must be set.
*1
No
setting
Must be
set.
Must be
set.
Segment Slope
0 to 9,999
(default: 0)
*2
EU/Time Unit of
Ramp Rate
No setting No
setting
Must be
set.
*2
No
setting
Segment Time 0.00 to 99.59
(default: 0.00)
Program Time Unit
(hours.minutes or
minutes.seconds)
Must be set. Must be
set.
No
setting
No
setting
This example is for setting the programming method to step time programming.
Operating Procedure
1 Press the M Key several times in the Initial Setting Level to
select the Step Time/Rate of Rise Programming parameter.
Initial Setting Level
2 Press the U or D Key to set time (step time programming).
The default is time (step time programming).
time
t-pr
Program
Time Unit
time
t-pr
