Omron E5CC-T User Manual

4 - 35
4 Basic Operation
E5@C-T Digital Temperature Controllers User’s Manual (H185)
4-7 Setting Programs
4
4-7-4 Making the Initial Program-related Settings
This parameter is set only for rate of rise programming. This parameter sets the time unit for the denom-
inator of the Segment Slope parameter.
z Related Parameters
z Setting Example
This parameter sets whether to perform control in reset status.
Here, “reset” means that the program is stopped.
• Stop Control (Default)
Control is stopped in reset status.
When operation is started again, program control or fixed SP control is started according to the
setting of the SP Mode parameter.
* When a program is in reset status, the segment number will be 0, the elapsed program time will be 0, hold
status will be cleared, the program repetition counter will be 0, and the program number will be the number
of the selected program.
• Fixed SP Operation
Fixed SP control is executed in reset status using the fixed SP.
When operation is started, Program SP Mode is automatically entered and control is started with the
program SP.
z Related Parameters
Setting the Time Unit of Ramp Rate Parameter (for Rate of Rise
Programming)
Parameter name Display Setting range Default Level
Time Unit of Ramp
Rate
pru
h: Hours
m: Minutes
m
Initial Setting Level
The following example shows how to set m (minutes).
Operating Procedure
1 Press the M Key several times in the Initial Setting Level to
select the Time Unit of Ramp Rate parameter.
Initial Setting Level
2 Press the U or D Key to set m (minutes).
The default is m (minutes).
Setting the Reset Operation Parameter
Parameter name Display Setting range Default Level
Reset Operation
rtsm
stop: Stop control
fsp: Fixed SP operation
stop
Initial Setting Level
m
pru
Time Unit of
Ramp Rate
m
pru
