6 - 77
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-9 Initial Setting Level
6
• This parameter sets the count that indicates the position where the valve is completely
closed.
• This parameter is set automatically when motor calibration is executed. There is normally
no need to change it manually.
• To use the results of automatic motor calibration calculations with another Digital
Controller, set the following parameters as a set: Travel Time, Valve Completely Closed
Position, Valve Completely Open Position, and Potentiometer Specification Setting.
However, these settings will depend on the equipment. When precise operation is
required, execute motor calibration separately for each piece of equipment.
z Related Sections
5-21 Controlling Valves (Can Be Used with a Position-proportional Model) (page 5-79)
z Related Parameters
Motor Calibration (Initial Setting Level): Page 6-76
vl-o
Valve Completely Open Position A Position-proportional Model must be used.
• This parameter sets the count that indicates the position where the valve is completely
open.
• This parameter is set automatically when motor calibration is executed. There is normally
no need to change it manually.
• To use the results of automatic motor calibration calculations with another Digital
Controller, set the following parameters as a set: Travel Time, Valve Completely Closed
Position, Valve Completely Open Position, and Potentiometer Specification Setting.
However, these settings will depend on the equipment. When precise operation is
required, execute motor calibration separately for each piece of equipment.
z Related Sections
5-21 Controlling Valves (Can Be Used with a Position-proportional Model) (page 5-79)
z Related Parameters
Motor Calibration (Initial Setting Level): Page 6-76
Function
Operation
Setting range Unit Default
0 to 9,999 --- 0
See
See
Function
Operation
Setting range Unit Default
0 to 9,999 --- 9999
See
See
