5 - 7
5 Communications Data for Modbus
E5@C Digital Temperature Controllers Communications Manual (H175)
5-1 Variable Area (Setting Range) List
5
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0C00 2C00 Input Type H'00000000 (0): Pt (−200 to 850°C/−300 to 1500°F)
H'00000001 (1): Pt (−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000002 (2): Pt (0.0 to 100.0°C/0.0 to 210.0
°F
)
H'00000003 (3): JPt (−199.9 to 500.0°C/−199.9 to 900.0°F)
H'00000004 (4): JPt (0.0 to 100.0°C/0.0 to 210.0
°F
)
H'00000005 (5): K (−200 to 1300°C/−300 to 2300°F)
H'00000006 (6): K (−20.0 to 500.0°C/0.0 to 900.0°F)
H'00000007 (7): J (−100 to 850°C/−100 to 1500°F)
H'00000008 (8): J (−20.0 to 400.0°C/0.0 to 750.0°F)
H'00000009 (9): T (−200 to 400°C/−300 to 700°F)
H'0000000A (10): T (−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000B (11): E (−200 to 600°C/−300 to 1100°F)
H'0000000C (12): L (−100 to 850°C/−100 to 1500°F)
H'0000000D (13): U (−200 to 400°C/−300 to 700°F)
H'0000000E (14): U (−199.9 to 400.0°C/−199.9 to 700.0°F)
H'0000000F (15): N (−200 to 1300°C/−300 to 2300°F)
H'00000010 (16): R (0 to 1700°C/0 to 3000°F)
H'00000011 (17): S (0 to 1700°C/0 to 3000°F)
H'00000012 (18): B (100 to 1800°C/300 to 3200°F)
H'00000013 (19): W (0 to 2,300°C/0 to 3,200°F)
H'00000014 (20): PLII (0 to 1,300°C/0 to 2,300°F)
H'00000015 (21): Infrared temperature sensor (K 140°F/60°C)
H'00000016 (22): Infrared temperature sensor (K 240°F/120
°C)
H'000
00017 (23): Infrared temperature sensor (K 280°F/140°C)
H'00000018 (24): Infrared temperature sensor (K 440°F/220°C)
H'00000019 (25): 4 to 20 mA
H'0000001A (26): 0 to 20 mA
H'0000001B (27): 1 to 5 V
H'0000001C (28): 0 to 5 V
H'0000001D (29): 0 to 10 V
H'0000001E (30): 0 to 50 mV*
* Selection is possible only for E5CC-U Controllers and only if they
are manufactured in May 2014 or later (version 2.2).
Initial setting
0C02 2C01 Temperature Unit H'00000000 (0): °C
H'00000001 (1): °F
0C12 2C09 Scaling Lower Limit H’FFFFF831 to scaling upper limit −1
(−1999 to scaling upper limit −1)
0C16 2C0B Scaling Upper Limit Scaling lower limit + 1 to H'0000270F
(Scaling lower limit + 1 to 9999)
0C18 2C0C Decimal Point H'00000000 to 00000003 (0 to 3)
0C1A 2C0D Remote SP Upper limit Input range lower limit to Input range upper limit for temperature input
Scaling lower limit to Scaling upper limit for analog input
Advanced
function
setting
0C1C 2C0E Remote SP Lower limit Input range lower limit to Input range upper limit for temperature input
Scaling lower limit to Scaling upper limit for analog input
0C1E 2C0F PV Decimal Point Display H'00000000 (0): OFF
H'00000001 (1): ON
0D06 2D03 Control Output 1 Signal H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
Initial setting
0D08 2D04 Control Output 2 Signal H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
0D1E 2D0F SP Upper Limit The range of values (without decimal point) is as follows:
Temperature input: SP lower limit + 1 to Input range upper limit
Analog input: SP lower limit + 1 to Scaling upper limit
0D20 2D10 SP Lower Limit The range of values (without decimal point) is as follows:
Temperature input: Input range lower limit to SP upper limit − 1
Analog input: Scaling lower limit to SP upper limit − 1
0D22 2D11 Standard or Heat-
ing/Cooling
H'00000000 (0): Standard
H'00000001 (1): Heating and cooling
To Next Page
