Omron E5EC Communications Manual

5 Communications Data for Modbus
5 - 8
E5@C Digital Temperature Controllers Communications Manual (H175)
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0D24 2D12 Direct/Reverse Operation H'00000000 (0): Reverse operation
H'00000001 (1): Direct operation
Initial setting
0D26 2D13 Close/Floating H'00000000 (0): Floating
H'00000001 (1): Close
0D28 2D14 PID ON/OFF H'00000000 (0): ON/OFF
H'00000001 (1): 2 PID control
0D2A 2D15 ST H'00000000 (0): OFF
H'00000001 (1): ON
0D2C 2D16 Program Pattern H'00000000 (0): OFF
H'00000001 (1): STOP
H'00000002 (2): CONT
0D30 2D18 Remote SP Input H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
H'00000002 (2): 1 to 5 V
H'00000003 (3): 0 to 5 V
H'00000004 (4): 0 to 10 V
Advanced
function
setting
0D32 2D19 Minimum Output ON/OFF
Band
H'00000000 to H'000001F4 (0.0 to 50.0)
0E00 2E00 Transfer Output Type H'00000000 (0): OFF
H'00000001 (1): Set point
H'00000002 (2): Set point during SP ramp
H'00000003 (3): PV
H'00000004 (4): MV (heating)
H'00000005 (5): MV (cooling)
H'00000006 (6): Valve opening (*Only for Position-proportional
Models.)
Initial setting
0E02 2E01 Transfer Output Signal H'00000000 (0): 4 to 20 mA
H'00000001 (1): 1 to 5 V

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
