Omron E5EC Communications Manual

5 - 9
5 Communications Data for Modbus
E5@C Digital Temperature Controllers Communications Manual (H175)
5-1 Variable Area (Setting Range) List
5
*1 P.END (program end output) can be set even when the program pattern is set to OFF, but the function will be disabled.
*2 Selection is possible only with the E5CC-U, E5DC, and E5GC and only when there is a control output that is a linear
current output.
(The E5CC-U must be manufactured in May 2014 or later (version 2.2 or higher) and the E5DC must be manufactured in
July 2014 or later (version 2.2 or higher).)
0E0C 2E06 Control Output 1 Assign-
ment
Control output 1 is a relay output or voltage output (for driving SSR):
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 4
H'00000007 (7): Heater alarm
H'00000008 (8): HB alarm
H'00000009 (9): HS alarm
H'0000000A (10): Input error
H'0000000B (11): RSP input error
H'0000000C (12): Program end output
*1
H'0000000D (13): RUN output
H'0000000E (14): Integrated alarm
H'0000000F (15): Work bit 1
H'00000010 (16): Work bit 2
H'00000011 (17): Work bit 3
H'00000012 (18): Work bit 4
H'00000013 (19): Work bit 5
H'00000014 (20): Work bit 6
H'00000015 (21): Work bit 7
H'00000016 (22): Work bit 8
When control output 1 is a linear current output:
H'FFFFFFFB (−5): Simple transfer MV (cooling)
*2
H'FFFFFFFC (−4): Simple transfer MV (heating)
*2
H'FFFFFFFD (−3):Simple transfer PV
*2
H'FFFFFFFE (−2): Simple transfer ramp SP
*2
H'FFFFFFFF (−1): Simple transfer SP*2
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
Advanced
function
setting
0E0E 2E07 Control Output 2 Assign-
ment
Control output 2 is a relay output or voltage output (for driving SSR):
H'00000000 to H'0000006 (0 to 22)
Note: Same as for the Control Output 1 Assignment parameter.
When control output 2 is a linear current output:
H'00000000 to H'00000002 (0 to 2)
Note: Same as for the Control Output 1 Assignment parameter,
except for items marked with “*2.”
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode

Omron E5EC Specifications

General

Mounting Type	Panel Mount
Display Resolution	0.1°C or 1°C
Control Method	ON/OFF
Input Type	Thermocouple, RTD, Analog voltage
Supply Voltage	100 to 240 VAC
Output Type	Relay, Voltage, Current
Size	48 x 96 mm
Control Output	Relay, Voltage, Current
Alarm Output	Relay
Communication	RS-485
Ambient Operating Temperature	-10 to 55°C
Ambient Operating Humidity	25 to 85% RH
Protection Rating	IP20
