5 Communications Data for Modbus
5 - 10
E5@C Digital Temperature Controllers Communications Manual (H175)
Address
Parameter name Setting (monitor) value Level
Four-byte
mode
Two-byte
mode
0E14 2E0A Event Input Assignment 1 H'00000000 (0): None
H'00000001 (1): RUN/STOP
H'00000002 (2): Auto/Manual Switch
H'00000003 (3): Program Start
*1
H'00000004 (4): Direct/Reverse Operation
H'00000005 (5): SP Mode Switch
*2
H'00000006 (6): 100% AT Execute/Cancel
H'00000007 (7): 40% AT Execute/Cancel
H'00000008 (8): Setting Change Enable/Disable
H'00000009 (9): Communications Writing Enable/Disable
*3
H'0000000A (10): Alarm Latch Cancel
H'0000000B (11): Multi-SP No. Switch, Bit 0
H'0000000C (12): Multi-SP No. Switch, Bit 1
H'0000000D (13): Multi-SP No. Switch, Bit 2
Initial setting
0E16 2E0B Event Input Assignment 2 H'00000000 to H'0000000D (0 to 13)
Note: Same as for Event Input Assignment 1.
0E18 2E0C Event Input Assignment 3 H'00000000 to H'0000000D (0 to 13)
Note: Same as for Event Input Assignment 1.
0E1A 2E0D Event Input Assignment 4 H'00000000 to H'0000000D (0 to 13)
Note: Same as for Event Input Assignment 1.
0E1C 2E0E Event Input Assignment 5 H'00000000 to H'0000000D (0 to 13)
Note: Same as for Event Input Assignment 1.
0E1E 2E0F Event Input Assignment 6 H'00000000 to H'0000000D (0 to 13)
Note: Same as for Event Input Assignment 1.
0E20 2E10 Auxiliary Output 1
Assignment
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 4
H'00000007 (7): Heater alarm
H'00000008 (8): HB alarm
H'00000009 (9): HS alarm
H'0000000A (10): Input error
H'0000000B (11): RSP input error
H'0000000C (12): Program end output
*4
H'0000000D (13): RUN output
H'0000000E (14): Integrated alarm
H'0000000F (15): Work bit 1
H'00000010 (16): Work bit 2
H'00000011 (17): Work bit 3
H'00000012 (18): Work bit 4
H'00000013 (19): Work bit 5
H'00000014 (20): Work bit 6
H'00000015 (21): Work bit 7
H'00000016 (22): Work bit 8
Advanced
function
setting
0E22 2E11 Auxiliary Output 2
Assignment
H'00000000 to H'00000016 (0 to 22)
Note: Same as for the Auxiliary Output 1 Assignment parameter.
0E24 2E12 Auxiliary Output 3
Assignment
H'00000000 to H'00000016 (0 to 22)
Note: Same as for the Auxiliary Output 1 Assignment parameter.
0E26 2E13 Auxiliary Output 4
Assignment
H'00000000 to H'00000016 (0 to 22)
Note: Same as for the Auxiliary Output 1 Assignment parameter.
0E28 2E14 Transfer Output Upper Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*2
Initial setting
0E2A 2E15 Transfer Output Lower Limit
H'FFFFF831 to H'0000270F (−1999 to 9999)
*2
*1 PRST (program start) can be set even when the program pattern is set to OFF, but the function will be disabled.
*2 Selection is possible only if there is a remote SP input.
*3 Selection is possible only if external communications is supported.
*4 The setting (monitor) range depends on the transfer output type setting. Refer to Section 6 Parameters in the E5
@
C
Digital Temperature Controller User’s Manual (Cat. No. H174).
*5 P.END (program end output) can be set even when the program pattern is set to OFF, but the function will be disabled.
