3 - 15
3 Communications Data for CompoWay/F
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
3
Variable
type
Address Parameter name Setting (monitor) value Level
C3 (83) 0050 Auxiliary Output 1
Assignment
H'00000000 (0): Not assigned.
H'00000001 (1): Control output (heating)
H'00000002 (2): Control output (cooling)
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 4
H'00000007 (7): Heater alarm
H'00000008 (8): HB alarm
H'00000009 (9): HS alarm
H'0000000A (10): Input error
H'0000000B (11): RSP input error
H'0000000C (12): Program end output
H'0000000D (13): RUN output
H'0000000E (14): Integrated alarm
H'0000000F (15): Work bit 1
H'00000010 (16): Work bit 2
H'00000011 (17): Work bit 3
H'00000012 (18): Work bit 4
H'00000013 (19): Work bit 5
H'00000014 (20): Work bit 6
H'00000015 (21): Work bit 7
H'00000016 (22): Work bit 8
Advanced
function setting
C3 (83) 0051 Auxiliary Output 2
Assignment
H'00000000 to H'00000016 (0 to 22)
Note: Same as for the Auxiliary Output 1
Assignment parameter.
C3 (83) 0053 Program Pattern H'00000000 (0): OFF
H'00000001 (1): STOP
H'00000002 (2): CONT
Initial setting
C3 (83) 0054 Soak Time Unit H'00000000 (0): Minutes
H'00000001 (1): Hours
H'00000002 (2): Seconds
*1
Advanced
function setting
C3 (83) 0055 Alarm SP Selection H'00000000 (0): Set point during SP ramp
H'00000001 (1): Set point
C3 (83) 0056 Auxiliary Output 3
Assignment
H'00000000 to H'00000016 (0 to 22)
Note: Same as for the Auxiliary Output 1
Assignment parameter.
C3 (83) 0057 Close/Floating H'00000000 (0): Floating
H'00000001 (1): Close
Initial setting
C3 (83) 0058 Travel Time H'00000001 to H'000003E7 (1 to 999)
*1 Selection is possible only with the E5DC and E5GC. (The D5DC must be manufactured in July 2014 or later
(version 2.2 or higher).)
