3 Communications Data for CompoWay/F
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
3
C3 (83) 008D Control Output 2
Signal
H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
Initial setting
C3 (83) 008E Transfer Output
Signal
H'00000000 (0): 4 to 20 mA
H'00000001 (1): 1 to 5 V
C3 (83) 008F Auxiliary Output 4
Assignment
H'00000000 to H'0000016 (0 to 22)
Note: Same as for the Auxiliary Output 1
Assignment parameter.
Advanced
function setting
C3 (83) 0090 Remote SP Input H'00000000 (0): 4 to 20 mA
H'00000001 (1): 0 to 20 mA
H'00000002 (2): 1 to 5 V
H'00000003 (3): 0 to 5 V
H'00000004 (4): 0 to 10 V
C3 (83) 0091 Integral/Derivative
Time Unit
H'00000000 (0): 1 s
H'00000001 (1): 0.1 s
C3 (83) 0092 Manual Output
Method
H'00000000 (0): HOLD
H'00000001 (1): INIT
C3 (83) 0093 Manual MV Initial
Value
Standard control or close position-proportional
control:
H'FFFFFFCE to H'0000041A (−5.0 to
105.0)
Heating and cooling control:
H'FFFFFBE6 to H'0000041A (−105.0 to
105.0)
C3 (83) 0094 Minimum Output
ON/OFF Band
H'00000000 to H'000001F4 (0 to 50.0)
C3 (83) 0095 Display Brightness H'00000001 to H'00000003 (1 to 3)
Variable
type
Address Parameter name Setting (monitor) value Level
