3 Communications Data for CompoWay/F
3 - 18
E5@C Digital Temperature Controllers Communications Manual (H175)
C3 (83) 0073 PV/SP No. 1 Display
Selection
H'00000000 (0): Nothing displayed.
H'00000001 (1): PV/SP
H'00000002 (2): PV
H'00000003 (3): PV/SP (character display)
H'00000004 (4): PV/SP/MV
H'00000005 (5): PV/SP/Multi-SP No.
H'00000006 (6): PV/SP/Soak time remain
H'00000007 (7): PV/SP/Internal SP (ramp SP)
H'00000008 (8): PV/SP/Alarm value 1
Advanced
function
setting
C3 (83) 0074 MV Display Selection H'00000000 (0): MV (heating)
H'00000001 (1): MV (cooling)
C3 (83) 0075 PV Decimal Point
Display
H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 0076 PV Status Display
Function
H'00000000 (0): OFF
H'00000001 (1): Manual
H'00000002 (2): Stop
H'00000003 (3): Alarm 1
H'00000004 (4): Alarm 2
H'00000005 (5): Alarm 3
H'00000006 (6): Alarm 4
H'00000007 (7): Alarm 1 to 4 OR status
H'00000008 (8): Heater alarm
H'00000009 (9): Status display message
*1
C3 (83) 0077 SV Status Display
Function
H'00000000 to H'00000009 (0 to 9)
Note: Same as for PV Status Display
Function
C3 (83) 0083 Display Refresh
Period
H'00000000 (0): OFF
H'00000001 (1): 0.25
H'00000002 (2): 0.5
H'00000003 (3): 1.0
C3 (83) 0084 Alarm 4 Type H'00000000 to H'00000013 (0 to 19)
Note: Same settings as the Alarm 1 Type.
However, the LBA (loop burnout alarm)
cannot be set.
Initial setting
C3 (83) 0085 Event Input
Assignment 5
H'00000000 to H'0000000D (0 to 13)
Note: Same as for Event Input Assignment 1.
C3 (83) 0086 Event Input
Assignment 6
H'00000000 to H'0000000D (0 to 13)
Note: Same as for Event Input Assignment 1.
C3 (83) 0087 Auxiliary Output 4
Open in Alarm
H'00000000 (0): Close in alarm
H'00000001 (1): Open in alarm
Advanced
function setting
C3 (83) 0088 Alarm 4 Hysteresis H'00000001 to H'0000270F
(0.1 to 999.9 for temperature input)
(0.01 to 99.99 for analog input)
Initial setting
C3 (83) 0089 Moving Average
Count
H'00000000 (0): OFF
H'00000001 (1): 2 times
H'00000002 (2): 4 times
H'00000003 (3): 8 times
H'00000004 (4): 16 times
H'00000005 (5): 32 times
Advanced
function setting
C3 (83) 008A Alarm 4 Latch H'00000000 (0): OFF
H'00000001 (1): ON
C3 (83) 008B Alarm 4 ON delay H'00000000 to H'000003E7 (0 to 999)
C3 (83) 008C Alarm 4 OFF delay H'00000000 to H'000003E7 (0 to 999)
*1 Selection is possible only with the E5DC and E5GC. (The D5DC must be manufactured in July 2014 or later
(version 2.2 or higher).)
Variable
type
Address Parameter name Setting (monitor) value Level
