3 - 17
3 Communications Data for CompoWay/F
E5@C Digital Temperature Controllers Communications Manual (H175)
3-1 Variable Area (Setting Range) List
3
C3 (83) 006D PF Setting H'00000000 (0): Disabled.
H'00000001 (1): Run
H'00000002 (2): Stop
H'00000003 (3): RUN/STOP
H'00000004 (4): 100% AT execute
H'00000005 (5): 40% AT execute
H'00000006 (6): Alarm latch cancel
H'00000007 (7): Auto/manual switch
H'00000008 (8): Monitor/setting item
H'00000009 (9): Digit shift key
Advanced
function setting
C3 (83) 006E Monitor/Setting Item
1
H'00000000 (0): Disabled
H'00000001 (1): PV/SP/Multi-SP
H'00000002 (2): PV/SP/MV
H'00000003 (3): PV/SP/soak time remain
H'00000004 (4): Proportional band
H'00000005 (5): Integral time
H'00000006 (6): Derivative time
H'00000007 (7): Alarm value 1
H'00000008 (8): Alarm value upper limit 1
H'00000009 (9): Alarm value lower limit 1
H'0000000A (10): Alarm value 2
H'0000000B (11): Alarm value upper limit 2
H'0000000C (12): Alarm value lower limit 2
H'0000000D (13): Alarm value 3
H'0000000E (14): Alarm value upper limit 3
H'0000000F (15): Alarm value lower limit 3
H'00000010 (16): Alarm value 4
H'00000011 (17): Alarm value upper limit 4
H'00000012 (18): Alarm value lower limit 4
H'00000013 (19): PV/SP/Internal set point
H'00000014 (20): PV/SP/Alarm value 1
H'00000015 (21): Proportional band (cooling)
H'00000016 (22): Integral time (cooling)
H'00000017 (23): Derivative time (cooling)
C3 (83) 006F Monitor/Setting Item
2
H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
C3 (83) 0070 Monitor/Setting Item
3
H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
C3 (83) 0071 Monitor/Setting Item
4
H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
C3 (83) 0072 Monitor/Setting Item
5
H'00000000 to H'00000017 (0 to 23)
Note: Same as for Monitor/Setting Item 1.
Variable
type
Address Parameter name Setting (monitor) value Level
