Overview of System Startup Procedure Section 2-1
A message will appear asking whether another tag set is to be created. If no
other tag sets are to be created, click the Close Button.
Note When tag data links operate, data is sent in the order in which the
tags are registered in the tag set. When combining tags into a tag
set, pay attention to the order and size of the tags.
The new tag set has been registered.
Also register the output tag set.
Select tags to be added to
the tag set.
Click here to register the
selected tags in the tag list.
Added to the tag list.
Input a name for the tag
set.
Click the OK Button.
Tag set A
Tag set B
Tag 3
Tag 4
Tag 1
Tag 2
The new tag has been
registered. When the
icon is double-clicked,
the tags in the tag set
will be displayed.
Click the Out-Produce
Tab, and register the
new tags in an output
tag set.
To Next Page
