30
Overview of System Startup Procedure Section 2-1
This completes the combining tags into a tag set.
Common Procedure 7-3. Setting Connections
This procedure is performed using the CJ2B-EIP21 Edit Device Parameters
Dialog Box.
A new output tag set is
registered.
1. Click the Connection Tab.
2. Select the link destination (SMC
EX250-SEN1 in this example).
3. Click this button to register the
selected device as the link
destination.
1. The SMC EX250-SEN1 has been
registered as the link destination.
2. Click the New Button to create
the connection.
