Omron ERT1 Series User Manual

31
Overview of System Startup Procedure Section 2-1
The dialog box for making connections will not close. If no more connections
are to be created, click the Close Button.
The new connection will be displayed in the Registered Device List.
After the connection settings have been made, a window like the one shown
below will be displayed.
1. Input a name for the connection.
2. Input the RPI.
3. Select the consume and produce
variables. Make sure that the
sizes are the same.
4. Also register the output variables.
5. To register the connection, click
the Register Button.
Click the OK Button to enable
the settings.
