Omron fh series Robot Connection Guide

17
3.1. Setting Communications for Robot controller
Please follow the procedures below to set the communications for the robot controller.
Connect a monitor, keyboard, and mouse to the robot's control box, and turn on the
robot's power.
1
Click [Get Control] on the
robot startup screen to make
the settings available.
If the robot is in auto mode,
switch to manual mode.
2
Click the icon in the top left
menu to display a list of the
function menu.
Click [System] – [Network].
3
Click [Local Area Connection
X] in Network setting.
Set the IP Address and Subnet
Mask.
Set the IP address that does
not overlap with the Vision
Sensor and the PC where
TMflow is running.

Omron fh series Specifications

General

Brand	Omron
Model	fh series
Category	Machine Vision Systems
Language	English
