Omron FQ2-S Series User Manual

Communicating with an External Device
16
FQ2-S/CH User’s Manual
for Communications Settings
EtherNet/IP
❍: Can connect U:Only some models can connect ✕: Cannot connect
No-protocol (TCP), No-protocol (UDP)
OMRON
No-protocol (FINS/TCP)
OMRON
MELSEC-QnAS
Series
--- --- Q2ASCPU,
Q2ASCPU-S1,
Q2ASHCPU, or
Q2ASHCPU-S1
✕ A1SJ71QE71N3-T
Series CPU Unit Interface
Direct connection with CPU
unit (built-in port)
Connection via EtherNet/IP
unit
SYSMAC NJ NJ501 or NJ301 ❍ CJ1W-EIP21
SYSMAC_CJ2 CJ2M or CJ2H U (Built-in port only.) CJ1W-EIP21
SYSMAC_CJ1 CJ1H or CJ1G ✕ CJ1W-EIP21
CJ1M U (Built-in port only.) CJ1W-EIP21
SYSMAC_CS CS1H, CS1D, or CS1G ✕ CS1W-EIP21
Series CPU Unit Interface
Direct connection with CPU
unit (built-in port)
Connection via Ethernet unit
SYSMAC CJ2 CJ2H or CJ2M --- CJ1W-ETN21
SYSMAC CJ1 CJ1H or CJ1G --- CJ1W-ETN21
CJ1M --- CJ1W-ETN21
SYSMAC CS CS1H, CS1D, or CS1G --- CS1W-ETN21
SYSMAC CP1 CP1L U (Built-in port only.) ---
CP1H --- CJ1W-ETN21
SYSMAC One NSJ --- NSJW-ETN21
Series CPU Unit Interface
Direct connection with CPU
unit (built-in port)
Connection via Ethernet unit
SYSMAC CJ2 CJ2H or CJ2M U (Built-in port only.) CJ1W-EIP21 or CJ1W-
ETN21
SYSMAC CJ1 CJ1H or CJ1G --- CJ1W-EIP21 or CJ1W-
ETN21
CJ1M U (Built-in port only.) CJ1W-EIP21 or CJ1W-
ETN21
SYSMAC CS CS1H, CS1D, or CS1G --- CS1W-EIP21 or CS1W-
ETN21
Series Model name CPU Unit CPU name Interface
Direct connection with CPU
unit (built-in port)
Connection via Ethernet unit
FQ2-S_CH_comm.book 16 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
