Index
438
FQ2-S/CH User’s Manual
for Communications Settings
Index
Numerics
0 Suppressed 173
A
ACK signal ON period 74
B
baud rate 197
binary data file load and save commands
183
BUSY signal 34
BUSY signal output polarity 44
C
character output 22
clearing measurement values 52
command (command area) 123
command list 202
command list (EtherNet/IP) 109
command list (No-protocol (TCP), No-proto-
col (UDP)) 177
command list (parallel connection) 46, 75
command list (PLC link) 132
command list (PROFINET) 156
command/response method 20
communication protocols for communica-
tion with the Sensor 12
connection compatibility 14
connection mode 124
control signals and status signals 18
D
data length 197
data output after measurements 21
data output period 94, 124, 147
decimal output form 173
delimiter 197
detailed EtherNet/IP communications spec-
ifications 433
digits of decimal 173
digits of integer 173
E
ERROR signal 51
errors
clearing 46
Ethernet no-protocol commands 176
EtherNet/IP 88
expanded mode 45
expression judgements 41
external trigger 36
F
field separator 173
FINS commands 190
FINS/TCP no-protocol commands 188
flow control 197
G
GATE ON delay 66
GATE signal ON period 94, 124, 147
H
handshaking 30, 70
I
individual judgements 41
input port No. 168, 190
interval timeout 198
L
Lighting control 75
line delimiter 175
M
max output data 124
measurement data 22
measurements
continuous 37, 46
models that are compatible with the com-
munications protocols 15
N
negative 45, 74, 173
NG string output on/off 101, 151, 175
no-protocol (TCP) 167
no-protocol (UDP) 167
no-protocol command 198
number of delay 66
O
One-shot output 43
OR output 44
OR signal 34
OUT0 to OUT3 output polarity 45
OUT1 Polarity 44
output (output area) 123
output control 66
output data size 93, 146
Output delay 43
output form 100, 151
output handshake 93, 123, 146
output IP address 168, 190
Output mode 44
output period 66
output polarity 74
output port No. 168
output string setup 101, 151, 175
Output time 43
output time 66
overall judgement 40
P
parallel connection 34
parallel data output 63
Parallel Interface Sensor Data Unit 60
parallel judgement outputs 62
parameter notation examples for command
control 200
parity 197
partial output ON/OFF 101, 151, 175
