Command Control
202
FQ2-S/CH User’s Manual
for Communications Settings
Command List
This section lists the commands that you can use with the FQ2 and the communications protocols for which
each command is supported.
Execution Commands
*: You can execute the same operation with the Measurement Execution Bit (parallel communications: TRIG) in the control signals.
OK: Applicable command, RST: Command with restricted execution, NA: Non-applicable command
Function Parallel
p. 46, p. 75
PLC link
p. 132
EtherNet/
IP
p. 109
PROFINET
p. 156
No-proto-
col (TCP/
UDP/RS-
232C)
p. 177
No-proto-
col (FINS)
p. 191
Executes one measurement. NA
*
OK NA
*
NA
*
OK OK
Starts continuous measurements. OK OK OK OK OK NA
Ends continuous measurements. OK OK OK OK OK NA
Clears the measurement values. OK OK OK OK OK OK
Clears all data from the data output buffer of the Sen-
sor.
NA NA OK OK NA NA
Clears the error output status (error output and error
indicator).
NA NA NA NA OK OK
Clears the statistical data (such as the number of mea-
surements, the number of NG overall judgments, the
NG rate, and other information since the power supply
was turned ON) produced by the logging function held
by the Sensor.
NA OK OK OK OK OK
Re-registers the reference values for all registered
items based on the previously loaded image.
OK OK OK OK OK OK
Executes teaching for all registered inspection items. OK OK OK OK OK OK
Updates reference data for the specified image adjust-
ment processing item (filter item/position compensation
item).
NA OK OK OK OK OK
Updates the reference data for the specified inspection
item.
NA OK OK OK OK OK
Re-registers the reference value for the specified posi-
tion compensation item based on the previously loaded
image.
NA OK OK OK OK OK
Re-registers the reference values for the specified
inspection item based on the previously loaded image.
NA OK OK OK OK OK
Sets the latest image or a specified logging image as a
registered image.
NA OK OK OK OK OK
Loads a registered image saved to the SD card or PC
Tool as the measurement image.
NA OK OK OK OK OK
Returns as is any character string sent by an external
device.
NA OK OK OK OK OK
Restarts the Sensor. OK OK OK OK OK OK
Executes the specified command after the specified
waiting time elapses.
NA NA NA NA OK NA
Turns the ERROR signal OFF. OK NA NA NA NA NA
Retries inspection by external signal. OK NA NA NA NA NA
Saves the current setting data (system data, scene
groups, and calibration data) in the Sensor.
OK OK OK OK OK OK
Clears the OR signal and D signals. OK NA NA NA NA NA
