Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
FQ2-S/CH User’s Manual
for Communications Settings
191
3
Controlling Operation and Outputting Data with an
Ethernet Connection
Type of command Command codes (hex) Function Reference
MRC+SRC com-
mand code
Vision Sensor com-
mand code
Execution commands 280F 00101010 Executes one measurement. p.372
280F 00102010 Clears the measurement values. p.373
280F 00102040 Clears the error output status (error output and
error indicator).
p.373
280F 00102060 Clears the statistical data p.374
280F 00103010 Saves the current setting data (system data,
scene groups, and calibration data) in the Sen-
sor.
p.374
280F 00104010 Re-registers the models for registered Search,
Shape search II, Sensitive search, and Color
data inspection items.
p.375
280F 00104020 Performs teaching for all applicable items. p.376
Execution commands 280F 00104021 Updates reference data for the specified image
adjustment processing item (filter item/position
compensation item).
p.377
280F 00104022 Updates the reference data for the specified
inspection item.
p.378
280F 00104031 Re-registers the reference value for the speci-
fied position compensation item based on the
previously loaded image.
p.379
280F 00104032 Re-registers the reference values for the speci-
fied inspection item based on the previously
loaded image.
p.380
280F 00108010 Sets the latest image or a specified logging
image as a registered image.
p.381
280F 00108020 Loads a registered image saved to the SD card
or PC Tool as the measurement image.
p.382
280F 00109010 Returns the text string (half-width alphanumeric
characters) sent by the external device as-is.
p.383
280F 0010F010 Restarts the Sensor. p.383
Scene control com-
mands
280F 00201000 Acquires the scene number that is currently
being used.
p.384
280F 00301000 Changes the scene number to be used. p.391
