Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
379
5
Appendices
● Re-register Reference Values (Position Compensation Item): 280F 00104031
This command re-registers the reference value for the specified position compensation item based on the
previously loaded image.
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Position compensation item num-
ber
(4 bytes)
28 0F 00104031 Position compensation item num-
ber 0 to 7 (1 digit max.)
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00104031
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Position compensation
item number
Specifies the item number of the position compensation item that will have its model re-registered. (0 to 7)
FQ2-S_CH_comm.book 379 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
