Command Control
380
FQ2-S/CH User’s Manual
for Communications Settings
● Re-register Reference Values (Inspection Item): 280F 00104032
This command re-registers the reference values for the specified inspection item based on the previously
loaded image.
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Inspection item number (4 bytes)
28 0F 00104032 Inspection item number from 0 to
31 (2 digits max.)
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00104032
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Inspection item number Specifies the item number of the inspection item that will have its reference values re-registered. (0 to 31)
Only "0" can be specified with the FQ2-S1 series.
