Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
381
5
Appendices
● Set a Registered Image: 280F 00108010
Sets the latest image or a specified logging image as a registered image.
Registered images are saved to the following directory on the SD card or PC Tool.
\Sensor name\REGIMAGE
*
The image specified as a registered image can be loaded as a measurement image with the Acquire
Registered Image command.
Acquire Registered Image p.382
A maximum of 1000 registered images (image registration number: 0 to 999) can be set.
* For the PC Tool, the data is saved in the "\..\My Documents\OMRON FQ\" folder.
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Registered image number
(4 bytes)
Registration
source (4 bytes)
Logging image
number (4 bytes)
28 0F 00108010 3 digits max. 1 digit max. 2 digits max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00108010
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Registered image num-
ber
Specifies the image to be loaded as the measurement image.
The image is registered in advance with the Set a Registered Image command and assigned a number. (0
to 999)
Registration source Specifies the image to be set as the registered image.
0: Latest measurement image
1: Sensor logging image
Logging image number This argument is only specified when setting the Sensor's logging images as registered images. (0 to 19)
If the registration source is 0: Latest measurement image, this argument is not required.
FQ2-S_CH_comm.book 381 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
