Command Control
382
FQ2-S/CH User’s Manual
for Communications Settings
● Acquire Registered Image: 280F 00108020
This command loads a registered image saved to the SD card or PC Tool as the measurement image.
The registered image is the latest image or a logging image that has been assigned a number between 0 and
999 and has been registered in advance with the Set a Registered Image command.
Set a Registered Image p.381
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Registered image number
(4 bytes)
28 0F 00108020 3 digits max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00108020
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Registered image num-
ber
Specifies the image to be loaded as the measurement image.
The image is registered in advance with the Set a Registered Image command and assigned a number.
(0 to 999)
