Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
383
5
Appendices
● Echo: 280F 00109010
This command returns the text string (half-width alphanumeric characters) sent by the external device as-is.
Format
Response Format
End Codes
Parameter Descriptions
● Reset Sensor: 280F 0010F010
This command resets the Sensor.
Format
Response Format
If process is completed normally, the Sensor is reset. There is therefore no response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Arbitrary char-
acter string
(4 bytes)
28 0F 00109010 2 words
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Arbitrary char-
acter string
(4 bytes)
28 0F End code 00109010 2 words
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Arbitrary character string Sets the character string to be returned as is. The character string set here will be the response.
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F 0010F010
FQ2-S_CH_comm.book 383 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
