Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
192
FQ2-S/CH User’s Manual
for Communications Settings
Commands to get status 280F 00205000 Acquires the Sensor's most recent error code. p.406
280F 00207010 Acquires the input status (allowed/prohibited)
for the communications protocol set with the
Set Communication Input Status command.
p.385
280F 00207020 Acquires the output status (allowed/prohibited)
for the communications protocol set with the
Set Communication Output Status command.
p.386
280F 00208010 Acquires the input signal ON/OFF status for the
specified parallel I/O terminal.
p.387
280F 00208020 Batch acquires the ON/OFF status for the all
parallel I/O input terminals other than the IN ter-
minals.
p.388
280F 00208030 Batch acquires the ON/OFF status for the IN
terminals.
p.389
280F 0020F000 Acquires the FQ2 execution status (execution
mode).
p.390
280F 00401010 Acquires parameters and measurement values
for a position compensation item or filter item.
p.399
280F 00401020 Acquires parameters and measurement values
for the specified inspection item.
p.400
280F 00401040 Acquires the value of the specified camera
parameter.
p.402
280F 00403000 Acquires the Sensor's software version. p.401
280F 00404010 Acquires the value set for the specified system
data.
p.403
280F 00404060 Acquires the terminal offset data that is added
to the IN0 to IN4 command parameters when
executing parallel commands.
p.404
280F 00406010 Acquires the statistical data (such as the num-
ber of measurements, number of NG overall
judgments, and other information, since the
power supply was turned ON) held by the Sen-
sor.
p.405
Type of command Command codes (hex) Function Reference
MRC+SRC com-
mand code
Vision Sensor com-
mand code
FQ2-S_CH_comm.book 192 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
