Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
403
5
Appendices
● Acquire System Data: 280F 00404010
This command acquires the value set for the specified system data.
System data numbers and details: p. 222
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
System data number (4 bytes)
28 0F 00404010 3 digits max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Acquired value
(4 bytes)
28 0F End code 00404010 Dependent on the
system data
(1,000 times the
actual value)
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
System data number* Specifies the number that corresponds to the system data to be acquired.
Acquired value Returns the specified system data.
