Command Control
402
FQ2-S/CH User’s Manual
for Communications Settings
● Acquire Camera Parameter: 280F 00401040
This command acquires the value of the specified camera parameter.
Camera parameter numbers: p. 219
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Camera parameter number
(4 bytes)
28 0F 00401040 3 digits max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Acquired value
(4 bytes)
28 0F End code 00401040 Dependent on the
camera parameter
(1,000 times the
actual value)
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Camera parameter num-
ber
*
Specifies the number that corresponds to the camera parameter to be acquired.
Acquired value Returns the specified camera parameter.
