Omron FQ2-S Series User Manual

Command Control
386
FQ2-S/CH User’s Manual
for Communications Settings
● Acquire Communication Output Status: 280F 00207020
This command acquires the output status (allowed/prohibited) for all the communications protocol set with the
Set Communication Output Status command.
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F 00207020
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Acquired value
(4 bytes)
28 0F End code 00207020 Acquired value
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Acquired value Returns the acquired communications protocol status.
1: Output allowed status
0: Output prohibited status
