Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
385
5
Appendices
● Acquire Communication Input Status: 280F 00207010
This command acquires the input status (allowed/prohibited) for the communications protocol set with the Set
Communication Input Status command.
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Communications protocol type to
be acquired (4 bytes)
28 0F 00207010 Communications protocol type to
be acquired
(1 digit max.)
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Communications protocol status
(4 bytes)
28 0F End code 00207010 Communications protocol status
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Communications proto-
col type to be acquired
Specifies the communications protocol type to be acquired.
0: No protocol (TCP, UDP, FINS)
1: No protocol (RS-232C)
2: Parallel I/O
3: Fieldbus
5: PLC link
Communications proto-
col status
Returns the acquired communications protocol status.
0: Input prohibited status
1: Input allowed status
