Omron FQ2-S Series User Manual

Command Control
FQ2-S/CH User’s Manual
for Communications Settings
405
5
Appendices
● Acquire Statistical Data: 280F 00406010
Acquires the statistical data (such as the number of measurements, number of NG overall judgments, and
other information, since the power supply was turned ON) possessed by the Sensor.
The following types of statistical data are available. Specify the data to be read from these types with this
command.
•Number of measurements since the power supply was turned ON
•Number of OK overall judgments
•NG rate
•Number of NG judgments since the power supply was turned ON
•OK rate
Command Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Type of statistical data to be
acquired (4 bytes)
28 0F 00406010 1 digit max.
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Acquired value
(4 bytes)
28 0F End code 00406010 Acquired value
(1,000 times the
actual value)
End code (hex) Description
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Type of statistical data to
be acquired
Specifies the type of statistical data to be acquired.
1: Number of measurements
2: Number of NG judgments
3: NG rate
4: Number of OK judgments
5: OK rate
Acquired value Returns the value of the acquired statistical data.
FQ2-S_CH_comm.book 405 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
