Omron FQ2-S Series User Manual

Command Control
400
FQ2-S/CH User’s Manual
for Communications Settings
● Get the Inspection Item Data: 280F 00401020
This command acquires the parameters and measurement values of the specified inspection item.
Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Inspection item number (4 bytes) External reference
number (4 bytes)
28 0F 00401020 Inspection item number (2 digits
max.)
External reference
number
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
Acquired value
(4 bytes)
28 0F End code 00401020 Acquired value
(1,000 times the
actual value)
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Inspection item number Specifies the number of the inspection item for which to acquire the data. (0 to 31)
External reference num-
ber
Specifies the external reference number.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
Acquired value Returns the data for the specified inspection item.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
FQ2-S_CH_comm.book 400 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
