Controlling Operation and Outputting Data with FINS/TCP No-protocol Commands
FQ2-S/CH User’s Manual
for Communications Settings
193
3
Controlling Operation and Outputting Data with an
Ethernet Connection
Commands to set status 280F 00307010 Sets the input status (allowed/prohibited) of the
communications port for the specified commu-
nications protocol.
p.392
280F 00307020 Sets the output status (allowed/prohibited) for
the specified communications protocol.
p.393
280F 00308010 Sets the output signal ON/OFF status for the
specified parallel I/O terminal.
p.394
280F 00308020 Batch sets the ON/OFF status for the all parallel
I/O output terminals other than the D terminals
(D0 to D15).
p.396
280F 00308030 Batch sets the ON/OFF status for the D termi-
nals (D0 to D15).
p.397
280F 0030F000 Sets the FQ2 execution status (execution
mode).
p.398
280F 00501010 Sets parameters for a position compensation
item or filter item.
p.407
280F 00501020 Sets parameters for the specified inspection
item.
p.408
280F 00501040 Sets the value for the specified camera param-
eter.
p.409
280F 00504010 Sets the value to the specified system data. p.410
280F 00504060 Sets the value of the terminal offset data that is
added to the IN0 to IN4 command parameters
p.411
Load setting data com-
mands
280F 00601000 Loads scene data that is stored on the SD card
inserted in the Touch Finder.
p.412
280F 00602000 Loads all scene data that is stored on the SD
card inserted in the Touch Finder.
p.413
280F 00603000 Loads system data that is stored on the SD
card inserted in the Touch Finder.
p.414
280F 00605000 Loads all setting data (all scene data, system
data, calibration group data) for the Sensor
saved as a backup file from the SD card
inserted in the Touch Finder.
p.415
280F 0060A000 Loads calibration data that is stored on the SD
card inserted in the Touch Finder as the calibra-
tion data with the specified number.
p.416
280F 0060B000 Loads all calibration data that is stored on the
SD card inserted in the Touch Finder.
p.417
280F 0060C000 Loads model dictionary data that is stored on
the SD card inserted in the Touch Finder as the
model dictionary with the specified number.
p.418
280F 0060D000 Loads all model dictionary data that is stored on
the SD card inserted in the Touch Finder.
p.419
Save setting data com-
mands
280F 00701000 Saves scene data to the SD card inserted in the
Touch Finder as a file.
p.420
280F 00702000 Saves all scene data as a file to the SD card
inserted in the Touch Finder.
p.421
280F 00703000 Saves system data as a file to the SD card
inserted in the Touch Finder.
p.422
280F 00704000 Saves image data saved in the Sensor’s mem-
ory by the logging function to the SD card
inserted in the Touch Finder as ifz data.
p.423
Type of command Command codes (hex) Function Reference
MRC+SRC com-
mand code
Vision Sensor com-
mand code
FQ2-S_CH_comm.book 193 ページ ２０１４年６月２６日 木曜日 午前１１時４７分
