Command Control
FQ2-S/CH User’s Manual
for Communications Settings
407
5
Appendices
● Set Image Adjustment Data: 280F 00501010
This command sets parameters or measurement ranges from a position compensation item or filter item.
Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Position compensation item/filter
item number (4 bytes)
External reference
number (4 bytes)
Set value (4 bytes)
28 0F 00501010 Position compensation item/filter
item number 0 to 7 (1 digit max.)
External reference
number
Setting value
(1,000 times the
actual value)
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00501010
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Position compensation
item number
Specifies the number of the position compensation item or filter item to set. (0 to 31)
External reference num-
ber
Specifies the external reference number.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
Set value Specifies the set value.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
