Omron FQ2-S Series User Manual

Command Control
408
FQ2-S/CH User’s Manual
for Communications Settings
● Set Inspection Item Data: 280F 00501020
This command sets the parameters and measurement ranges of the specified inspection item.
Format
Response Format
End Codes
Parameter Descriptions
MRC
(1 byte)
SRC
(1 byte)
Vision Sensor command code
(4 bytes)
Inspection item number (4 bytes) External reference
number (4 bytes)
Set value (4 bytes)
28 0F 00501020 Inspection item number from 00
to 1F (2 digits max.)
External reference
number
Set value (1,000
times the actual
value)
MRC
(1 byte)
SRC
(1 byte)
MRES
(1 byte)
SRES
(1 byte)
Vision Sensor command code
(4 bytes)
28 0F End code 00501020
End code (hex) Meaning
0000 Command execution ended normally.
FFFF Command execution ended in an error.
Inspection item number Specifies the number of the inspection item to set. (0 to 31)
External reference num-
ber
Specifies the external reference number.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
Setting Specifies the set value.
Section 9-2 External Reference Parameters
in Vision Sensor FQ2-S/CH Series User's Manual (Cat. No. Z337)
